What Are Dental Implants?

A titanium root, an abutment, and a crown: 50 years of evidence behind them. Here is what they actually are.

Dr. Henry Qiu, DDS

Dr. Henry Qiu, DDS

UCLA Implant FacultyUpdated 2026-05-13

A family raising glasses around a candle-lit outdoor dinner table at golden hour

01

The short answer

A dental implant is a small titanium screw placed into the jawbone to replace the root of a missing tooth. Once the bone fuses to it — a process called osseointegration — a crown is attached on top. The result looks, functions, and lasts like a natural tooth.

Three parts, no moving pieces: the implant (the root), the abutment (the connector), and the crown (the visible tooth). When all three are placed correctly, the implant behaves as if it had always been part of your mouth.

Modern implants have been used for over 50 years. Long-term studies show 95–98% survival at 10 years and routine 25+ year function with good hygiene. They do not decay, do not need root canals, and do not require reshaping adjacent teeth the way a bridge does.

02

The three parts of an implant

The implant body. A medical-grade titanium screw, typically 8–14 mm long and 3–6 mm wide, placed surgically into the jawbone. Titanium is chosen because bone cells grow directly onto its surface — a property no other metal shares at the same scale.

The abutment. A small connector that screws into the implant and protrudes through the gum. It is the only part you might see in a mirror before the final crown is bonded. We use zirconia abutments when esthetics matter — they avoid the gray shadow titanium can cast through thin gum tissue.

The crown. The visible tooth. Our standard is full-contour zirconia: indistinguishable from a natural tooth, biocompatible, and covered by our 10-year biological warranty along with the implant beneath it.

03

How osseointegration actually works

Osseointegration is the biological process where living bone cells migrate directly onto the surface of the titanium implant and lock it in place. It was discovered accidentally in 1952 by a Swedish researcher who found he could not remove titanium chambers from rabbit femurs after a few months — the bone had fused to them.

The process takes 8–14 weeks in the lower jaw and 12–18 weeks in the upper jaw, where bone density is lower. During that window, the implant is left undisturbed under the gum. Once integration is complete, the bond is mechanically stronger than the original tooth root.

We use the Vampire Implants™ Protocol on every placement — your own platelet-rich plasma is layered onto the implant before insertion, which accelerates integration by 30–40% and dramatically reduces inflammation in the first 72 hours.

04

What an implant can replace

A single tooth. One implant, one crown. The most common case. We do these in two visits spread across about 4 months — one to place, one to crown.

Several teeth in a row. Two implants can support a 3- or 4-unit bridge, avoiding the need to crown healthy teeth on either side.

A full arch. Six implants can support 12+ teeth — what we call All-on-6. The full set of teeth is bolted in. No adhesive, no removal, no slipping.

05

Why we recommend implants over bridges or dentures

A traditional bridge requires us to grind down the healthy teeth on either side of the gap. Those teeth become permanently weaker. About 30% will need a root canal within 10 years from the trauma of being reshaped. An implant leaves neighboring teeth completely untouched.

Dentures sit on the gums. Without a root to stimulate it, the jawbone underneath gradually resorbs — you lose roughly 25% of bone width in the first year alone. Five years later, dentures stop fitting and need relining or replacement. Implants stop that bone loss because they act like a real root.

The trade-off is upfront time. An implant takes 3–4 months from start to crown. A bridge can be done in two weeks. We think the longer timeline is worth it — patients who choose implants in their 50s rarely need to revisit the decision in their 70s.

06

What they cost and how long they last

A single implant at 5D Smiles is $3,500 all-inclusive — that is the consult, the 3D CBCT scan, the implant, the abutment, and the final zirconia crown. There are no add-on fees once the treatment plan is signed. Full-arch (All-on-6) starts at $20,000 per arch with the bone graft included.

Long-term studies put 10-year implant survival at 95–98%. The implant body itself routinely lasts 25+ years; at our practice, the implant and crown together are covered by our 10-year biological warranty — if it fails biologically (osseointegration, peri-implantitis, bone loss), we redo everything: surgery, parts, lab, all on us. Most patients never need to think about it again after the final crown is bonded.

The biggest variable in longevity is hygiene. Implants do not decay, but the gum and bone around them can become inflamed if not cleaned properly — a condition called peri-implantitis. We teach you exactly how to clean around them at the final delivery appointment.

A dental implant is a small titanium screw placed in the jawbone to replace a missing tooth root. Once bone fuses to it (osseointegration), a crown goes on top. The result looks, functions, and lasts like a natural tooth. At 5D Smiles in Downey, CA, Dr. Qiu places every implant himself using CT-guided planning and the Vampire Protocol for faster healing.

ADA reports a 90 to 95% implant success rate over 10 years when placement protocols are followed. AAID estimates 3 million+ Americans have implants, growing by 500,000 per year. PubMed research on osseointegration and long-term implant survival confirms that properly integrated titanium implants routinely function for 25+ years with no systemic toxicity, supporting the confidence Dr. Qiu places behind the 5D Smiles 10-year biological warranty.

By the numbers

1965

Year Brånemark first documented osseointegration with titanium in human jaws.

95%+

10-year implant body survival per ADA-cited long-term studies.

3 parts

Implant body, abutment, and crown, all placed at our Downey office by Dr. Qiu.
